Fueltech Peak-And-Hold Injector Driver – 4A/1A Output (Model 3010003324)

Description

Brand: FuelTech
Manufacturer’s Part Number: 3010003324
Part Type: Fuel Injector Driver Modules
Product Line: FuelTech Peak and Hold 4A/1A Injector Drivers
Automotive Fittings Part Number: FCH-3010003324
UPC: 7898633930077
Remanufactured: No
Quantity: Sold individually.
Description:
FuelTech Peak and Hold 4A/1A injector drivers are 4-channel low impedance units designed to keep up with the demands of today’s high horsepower engine fuel injectors. The Peak and Hold circuit opens the injector with a high current (Peak) pulse–and then switches the current down to hold the injector open to feed the volume.
Additional details:
* Controls up to 4 injectors with 1.5 to 3 ohms of impedance
* 8 Bosch 160 lbs./h (1600cc) injectors (2 per channel)
* 4 Siemens 83 lbs./h injectors
* 4 MSD injectors (with 2 ohms impedance per injector)
Contents of package:
* 1 Peak and Hold 4A/1A
* 1 operation and installation guide
* 1 mounting kit (four rubber mounts, four washers and four 1/4 in. nuts)
* 6 ft. Peak and Hold unterminated harness (optional)
* 1 FuelTech black carbon fiber sticker
